Quick Details

  • Use: Truck Trailer
  • Type: Semi-Trailer
  • Material: Steel
  • Certification: CCC BV SGS
  • Size: 11400*2500*3450mm
  • OEM No.: DRZ9300
  • Max Payload: 30T-60T
  • Place of Origin: Hubei, China
  • Brand Name: DRZE
  • Color: White
  • Keywords: oil Tank Trailer
  • Tanker Body Material: Carbon Steel Q235B, 6 mm
  • Axle: 2 FUWU / L1 /BPW 13 ton
  • Tire: 12R22.5 tubeless tire with two spare tire, 14 pieces
  • Wheel rim: 9.0-22.5 wheel rim, 14 pieces
  • Tank Body: Double D shape
  • MOB: +86-152-71357675

Packaging & Delivery

Packaging Details Parts SKD By containers WhatsApp:86.152.7135.7675 Skype:tomsongking
Trucks /Trailers by Ro-Ro or Bulk base on the ship and port in your country. If the truck on the deck,
we will spray antirust paint with free. Usually we will put the truck in cabin of the ship.
Port Shanghai

Factory Wholesale Price 2 Axle Petrol Fuel Tank Semi Trailer Oil Transporting Tanker Semi Trailer



Stainless Steel Fuel Tank Trailer  36000 Liters to 45000 liters

45000 Liters Carbon Steel Oil Diesel Fuel Gasoil Gasoline Jet Fuel Tank Semi Trailer
Function: Transport Oil/Diesel/Fuel/Gasoil/Gasoline/Jet Fuel etc
Tank Volume: 36000Liters
Pay Load: 36000Kgs
Tanker Body Material: Q235B
Suspension:Mechanical suspension reinforcement
Landing Gear: 28Tons linkage external
Axle: 2 Axles FUWA brand 13T
Tyre: Triangle 12.00R22.5* (Include 1set spare tire )

Factory 2 Axle 6000 Gallon Fuel Tank Semi Trailer Africa



Main Parameter of 3 Axles Special Vehicle Diesel/Fuel/Petrol/Tank Gas Oil/Tanker Truck Trailer
Tank BodyChassis
ShapeSquare(optional)Main Beam

Welding design , connected by bolts and nuts

Material:Q345 carbon steel

Dimension(L*H*W)12800*2500*3950mm(adjustment)Axle3 axles, FUWA or BPW brand
Tare weightAbout 8-12.8TLanding GearChina brand 28T
Total Volume30-65m³King PinJOST 3.5 inch bolt-in king pin
Tanker Body Material6mm Aluminum AlloySuspensionMechanical suspension
End Plate6mm Aluminum AlloyLeaf Spring90(Width)mm×13(Thickness)mm×10(Layer))
Manhole Cover

Aluminum alloy API manhole cover.

Diameter: 500mm

Pneumatic Braking System

WABCO RE 6 relay valve; Spring brake chamber;

2 pieces of 45L air tanks

Bottom ValveAluminum API Pneumatic Bottom ValveRim22.5
Discharging Valve4 inchesTire315/80R22.5,12R22.5
CompartmentsOptionalABSYes
Discharging Pipe4" rubber hose, 2 pcs, 6m/eachPainting

complete chassis sand blasting to clean rust,

1 coat of anticorrosive prime, 2 coats of final paints

Cat WalkWith(Common model)AccessoriesOne standard tool box

Kindly Note:

Above parameter is just for your reference, we can customize different kinds of tank trailer as per your request.





1) Main beam adopt Q345 carbon steel. special design,connected by bolts and nuts with tanker body.

2) Advanced technology: Major parts and components of the trailer are processed by advanced equipments. Longitudinal beams are finished by automatic tracking submerged arc welding machine; all the sub-assemblies are shot-blasted to improve paint adhesiveness and are painted before assembling.

3) Hot-rolled structural steel welded 16Mn steel longitudinal beam and cross member are assembled and welded for chassis assembly. The finished chassis offers bending and deforming resistance with proper rigidity and streng

4) High performance domestic and imported axles with ABS system optionally available can significantly increase driving safety.

5) Large capacity water-proof detachable tool box.

6) Reliable dual circuit air brake with quick release valve and quick repines of wheel cylinder ensures safe on-road and off-road operation.







After-sales service:

Tank semi trailers with reasonable structure,reliable performance,beautiful appearance and simple operation, adopts computer 3D

aided design,Use high quality high strength steel produce,welded by automatic submerged-arc processes. All our spare parts(original,

OEM and replacement) for different types tank semi trailers with better price and nice quality to ensure customers' trucks and semi trailers

being in good working conditions.

Customize Service:

As a professional tank semi trailer manufacturer for many years, we can customize different kinds of tank trailer as per your requirement.

Payload from 20ton up to 100 ton to meet different road transportation demand,We will try our best to supply you an innovative and

efficient transport solution with super quality and competitive price. Expect our cooperation.

2 3 4 axle carbon steel material 45000 liters tank trailers diesel fuel tanker semi trailer for sale
Model DRZ400GYY
Wheel Base 1310 (mm)
Tyre Specifications 11.00R20 or option 12R22.5
No. Of the Tyres 8/12/16 pcs ISO Certificated
Axle 13/14/16/18Tonnage
No. Of the Axles 2 /3/4 pcs
Landing Gear 28 ton capacity Fuwa with static capacity of 80T
Suspension Heavy duty mechanic suspension with 10 pcs leaf spring
King Pin 2' and 3.5' interchangable traction pin
Departure Angle 15
Front/Rear Overhang 1900 mm
Material of the Main Beam Automatic submerged arc welded
Main beams Q345B/ST52-3, through cross beams Q235
Body material Q235B manganese plates, automatic
submerged arc welded
Brake System Automatic air brakes
Double pipe line air brake, front two axle is 30 air chamber.
rear axle is 30/30 air chamber.
Color As the buyers' requirement.
Accessory One tooling boxes ,Two spare tire carrier, Two fire extinguisher
Tanker side thickness 5mm carbon steel
Net Weight 12 T
Oil tanker 1000 liters Round Shape
Spare tire carrier 1 set
Electrical System 24V, 7core socket, lights according to European standards.
Tool Box 1 box of standard tools
